Honing Tool Components
At Ohio Tool Works, we know that your honing operational efficiency can come down to a single honing tool component. That's why we've designed and built a complete range of standard and custom parts to fit nearly every tooling system, eliminate operational downtime, and ensure maximum total honing tool life.
Indeed, no matter what brand or diameter of honing tooling you currently use, OTW has you covered for all your tooling component needs. From expander pins through fixturing, we offer the complete scope of new and replacement tooling parts for Ohio Tool Works tooling systems, as well as replacement parts suitable for a variety of other industry standard tooling systems such as General Hone, Barnes, and more.
In addition to tooling components, OTW offers standard and custom tooling assemblies, replacement honing tools, abrasive stones and various honing supplies, for an all-in-one honing resource. As with all OTW products, the difference between our tooling components and our competitors' is total quality and precision.
View the information below for range of sizes we offer as standard components or download our extensive catalog of honing tool assemblies, components and abrasives.
Need something special? OTW’s engineering team can assist with special honing tool requirements.
| Product | Size Range |
|---|---|
| Expander pins | 3.5" - 17" |
| Expander plates | 2" and below - 8" |
| Universal blocks | 1.25" - 16" |
| Drive screws and pins | 1.25" - 16" |
| Drive shanks | 1.25" - 22" |
| Ring nuts | 1.25" - 22" |
| Cones | 1" - 16" |
| Cone rod components | 1.25" - 24" |
| Utilization | 1.25" - 16" |
| Spindle nuts | N/A - 2.25" Spline |
| Spindle drive keys | N/A |
| Split collars | 1.25" - 2.25" Spline |
| Driveshaft assemblies | Up to 1" - 6" |
| Driveshaft socket | 0.75"- 3" |
| Drive keys | 0.75" - 3" OTW |
| Key sleeve | 0.75" - 3" |
| Driveshaft shanks | 2" - MPS Yoke |
| Feed rod cap | 0.75" - 4" |
| Feed screw assembly | 2" - 3" |
| Rotary feed screw | N/A |
| Adjusting head | 2" - 4" |
| Drive adapters | 2" - 4" |
| Morse taper shanks | N/A |
| Adusting head gears | N/A |
| Retaining springs | 0.625" x 6" - 0.25" x 12" |
| Spanner wrenches | (0.75" - 2") - (2" - 4.75") |
| Pigtail springs | 1.25" Tools - 1.5" + Tools |
| OTW fixtures | N/A |
| Fixture components | N/A |
Most OTW tooling and abrasives are compatible with many major honing brands such as Barnes, Century, Gehring, General Hone, Kadia, Micromatic, Nagel, Sunnen, Superior, and more.
Contact OTW or more information about our honing tool components or call 419-281-3700.
